UniFi Dream Router (Early Access)
Series Type: UniFi Dream Router
Website Link: https://store.ui.com/collections/early-access/products/dream-router-ea
Model: UDR
Type: Home or Small Business router with integrated AP
Description: The Dream Router (UDR) is a next-generation WiFi 6 router that delivers unbeatable performance at an unmatched price. Featuring advanced 4x4 MU-MIMO and OFDMA technology, the UDR has an aggregate wireless throughput rate of up to 3 Gbps over its 2.4 and 5 GHz bands, ensuring quality connectivity for all of your devices. The UDR also has (5) GbE RJ45 ports, including two that supply PoE to compatible devices, and all of its connections can be conveniently monitored from the router's LCM color screen. Designed to be a comprehensive, easy-to-use network hub, the UDR can be set up and configured in minutes via the UniFi Network web application or mobile app.
Features
- High‐Performance Dual Band Wi-Fi 6 AP
- Managed 4-Port Gigabit Switch with two dedicated PoE ports
- Advanced Security Gateway with IDS/IPS and DPI
- UniFi Network Controller with Intuitive User Interface
- Scalable Through Additional UniFi Devices Connected to LAN
UniFi Dream Machine Platform Notes
- UDM/UDR appliances have built in UniFi controllers and cannot be adopted by external controllers.
- Multiple sites are no longer supported on UDM/UDR platforms.
Hardware Revisions
| Revision | Feature / Changes |
|---|---|
| 23 | initial release |
Specifications
| UDR | |
|---|---|
| Dimensions | Ø 110 x 184.2 mm (Ø 4.33 x 7.25") |
| Weight | 1.15 kg (2.54 lb) |
| Networking Interfaces | (4) LAN 10/100/1000 RJ45 Ports (1) WAN 10/100/1000 RJ45 Port |
| Buttons | Reset |
| IDS/IPS Throughput | 700 Mbps 1) |
| Processor | Dual-Core® Cortex® A53 at 1.35 GHz |
| System Memory | 2 GB DDR RAM |
| On-Board Flash Storage | 16 GB |
| Maximum Power Consumption | 50W |
| Supported Voltage Range | 100 - 240VAC |
| Power Method | AC Power Cord |
| Power Supply | Internal AC/DC Power Adapter (1.1A) |
| Power Save | Supported |
| Beamforming | Supported |
| TX Power* 2.4 GHz 5 GHz | 26 dBm 26 dBm |
| Antenna | (1) Dual-Band, Quad-Polarity Antenna |
| Antenna Gain 2.4 GHz 5 GHz | 3.4 dBi 4.3 dBi |
| Wi-Fi Standards | 802.11a/b/g/WiFi 4/WiFi 5/WiFi 6 |
| Wireless Security | WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3) |
| BSSID | Up to 8 per Radio |
| Operating Temperature | -10 to 45° C (14 to 113° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Certifications | CE, FCC, IC |
* Including antenna gain. Maximum TX power level may be limited by user's country-specific regulations.
Getting Started
- When installing UDR for the first time from initial EA batch, upgrade the firmware to latest version and after that factory reset the device. This will resolve issues present in the initial version of the firmware.
Known Issues
- Due memory limitations UDM/UDR only supports 11 IDS/IPS categories, network application shows incorrect information.
- Integrated SSD is not shown in UDM SE settings, to check storage status you need to use ssh.
- LCM crashes and/or slows down when system is under heavy load.
